Product introduction
DTE brand D3 LED ultrasonic scaler product is suitable for dental calculus removal, and is an important equipment for dental disease prevention and treatment.
1. The features of this equipment are:
a) The handle has LED light, which is more convenient for clinical operation;
b) The automatic frequency tracking system is adopted to automatically search for the best working state, and the machine performance is stable;
c) The working handle can be freely pulled out and inserted, and can be sterilized at a high temperature of 134°C and a high pressure of 0.22MPa;
d) The working process is fully controlled by microcomputer, the operation is convenient and simple, and the efficiency is high.
2. Model Specifications
D3 LED type
3. Machine configuration The machine configuration is detailed in the packing list.
4. Performance structure and composition It is composed of host, handle, working tip, foot switch and power adapter.
5. Scope of application Suitable for dental stone removal.
1. The features of this equipment are:
a) The handle has LED light, which is more convenient for clinical operation;
b) The automatic frequency tracking system is adopted to automatically search for the best working state, and the machine performance is stable;
c) The working handle can be freely pulled out and inserted, and can be sterilized at a high temperature of 134°C and a high pressure of 0.22MPa;
d) The working process is fully controlled by microcomputer, the operation is convenient and simple, and the efficiency is high.
2. Model Specifications
D3 LED type
3. Machine configuration The machine configuration is detailed in the packing list.
4. Performance structure and composition It is composed of host, handle, working tip, foot switch and power adapter.
5. Scope of application Suitable for dental stone removal.
The main technical parameters
- Power input: ~220V 50Hz
- Input power: 38VA
- Host input: ~24V 50Hz l.3A1.8.3
- Output tip main vibration offset: 1μm～100μm1.8.4
- Output tip vibration frequency: 28kHz±3kHz1.8.5
- Output half offset force: 0.1N～2N1.8.6
- Cutting edge output power: 3W～20W1.8.7
- Host insurance: T1.6AL 250V1.8.8
- Power adapter insurance: T0.5AL 250V1.8.9
- Water inlet pressure: 0.1bar～5bar (0.01MPa～0.5MPa)
- Host weight: 0.66kg
- Power adapter weight: 1kg
Use environment
- Ambient temperature: +5℃～+40℃
- Relative humidity: 30% ~ 75%
- Atmospheric pressure: 70kPa～106kPa
- Inlet water temperature: ≤ +25℃
Good assistant for dentists
- Detachable handpiece with light , better visibility.
- Handpiece adopts latest sealing technique ,bringing patients more comfortable scaling.
- Automatic degenerative feedback, constant power outpu, tand more comfortable scaling.
TIPS
- Soft and painless scaling
- Athermic tips
Detachable handpiece with light
- Shell of the handpiece is made of special imported plastic from America
- Without cracking or deformation under the pressure
- Detachable handpiece with light , better visibility
- Note : This type can match with handpiece without light .
